一、產品概述

并(bing)聯電(dian)(dian)(dian)(dian)(dian)抗器(qi)用(yong)于(yu)補償線路的(de)(de)(de)電(dian)(dian)(dian)(dian)(dian)容(rong)(rong)性充電(dian)(dian)(dian)(dian)(dian)電(dian)(dian)(dian)(dian)(dian)流，限制系(xi)(xi)統工(gong)頻電(dian)(dian)(dian)(dian)(dian)壓(ya)的(de)(de)(de)升高(gao)(gao)和操作過電(dian)(dian)(dian)(dian)(dian)壓(ya)，從而降低系(xi)(xi)統的(de)(de)(de)絕(jue)緣水(shui)平(ping)，保證線路的(de)(de)(de)可靠(kao)運行。隨著(zhu)我國(guo)城市(shi)規模的(de)(de)(de)不(bu)斷擴大(da)及城市(shi)電(dian)(dian)(dian)(dian)(dian)網的(de)(de)(de)改造，架空線路輸(shu)電(dian)(dian)(dian)(dian)(dian)逐漸(jian)被(bei)地下電(dian)(dian)(dian)(dian)(dian)纜輸(shu)電(dian)(dian)(dian)(dian)(dian)所替代，使得輸(shu)電(dian)(dian)(dian)(dian)(dian)網絡(luo)的(de)(de)(de)對地電(dian)(dian)(dian)(dian)(dian)容(rong)(rong)性充電(dian)(dian)(dian)(dian)(dian)電(dian)(dian)(dian)(dian)(dian)流急劇增大(da)，為了降低系(xi)(xi)統工(gong)頻電(dian)(dian)(dian)(dian)(dian)壓(ya)的(de)(de)(de)升高(gao)(gao)和系(xi)(xi)統絕(jue)緣水(shui)平(ping)，保證系(xi)(xi)統的(de)(de)(de)安(an)全可靠(kao)運行和城市(shi)的(de)(de)(de)電(dian)(dian)(dian)(dian)(dian)網供電(dian)(dian)(dian)(dian)(dian)質(zhi)量(liang)，在高(gao)(gao)壓(ya)及超高(gao)(gao)壓(ya)、遠距離輸(shu)電(dian)(dian)(dian)(dian)(dian)系(xi)(xi)統中(zhong)廣泛應用(yong)的(de)(de)(de)并(bing)聯電(dian)(dian)(dian)(dian)(dian)抗器(qi)在城市(shi)配(pei)電(dian)(dian)(dian)(dian)(dian)電(dian)(dian)(dian)(dian)(dian)網中(zhong)得到較普遍的(de)(de)(de)應用(yong)。

二、 結構特點

1.電抗器由(you)計(ji)算機設計(ji)軟件優(you)化設計(ji)，可按照用戶特(te)殊要求快速準(zhun)確設計(ji)最(zui)佳(jia)理想的電氣性能和結構參數。

2.線(xian)圈(quan)(quan)采用高強度(du)雙玻(bo)璃(li)(li)薄(bo)膜(mo)線(xian)繞制而成(cheng)，線(xian)圈(quan)(quan)內外敷設環(huan)(huan)氧玻(bo)璃(li)(li)網格(ge)布增強，由環(huan)(huan)氧樹脂(zhi)真空(kong)澆(jiao)注(zhu)，保(bao)證絕緣性能優(you)良，機械強度(du)高的特點(dian)。

3.鐵芯選用優質硅(gui)鋼片，鐵芯片用進口喬格(ge)線自動剪切(qie)(qie)完成縱、橫(heng)剪切(qie)(qie)，確保(bao)鐵芯加工質量。

4.鐵芯采(cai)用高強度(du)玻(bo)璃絲帶包扎熱(re)固(gu)定和優(you)質環氧(yang)樹(shu)脂(zhi)澆注工藝，使鐵餅間(jian)的氣(qi)隙被(bei)環氧(yang)樹(shu)脂(zhi)封閉，有效(xiao)減少(shao)鐵芯餅之間(jian)的震動，從而降低噪音(yin)。

5.產品具有阻燃性(xing)(xing)、防潮濕、環保、損耗小、噪聲低、安(an)裝簡便、電氣性(xing)(xing)能好(hao)、運行可靠性(xing)(xing)高。

三、 性能參數

額(e)定(ding)電壓(ya)：3KV、6kV、10kV、35kV

額定頻(pin)率：50Hz、60Hz

絕緣(yuan)等(deng)級：F級

聯(lian)結組別：Y

額定電抗率：100%

四、型號說明

五、使用環境條件

1.海拔高度不(bu)超過2000米；

2.運行環(huan)境溫度(du)-25℃至+45℃，相(xiang)對濕度(du)不超過90%；

3.周圍無有害氣體(ti)，無易燃易爆(bao)物品；

4.周圍環境應有良好(hao)的通風條件。
